Basic Functions of Arduino

Basic Functions of Arduino

Configures the specified pin to behave either as an input or an output and other basic operation.

pinMode()

Description

Configures the specified pin to behave either as an input or an output. See the Digital Pins page for details on the functionality of the pins.

As of Arduino 1.0.1, it is possible to enable the internal pullup resistors with the mode INPUT_PULLUP. Additionally, the INPUT mode explicitly disables the internal pullups.

Syntax

pinMode(pin, mode)

Parameters

pin: the Arduino pin number to set the mode of.
modeINPUTOUTPUT, or INPUT_PULLUP. See the Digital Pins page for a more complete description of the functionality.

Returns

Nothing



digitalWrite()

Description

Write a HIGH or a LOW value to a digital pin.

If the pin has been configured as an OUTPUT with pinMode(), its voltage will be set to the corresponding value: 5V (or 3.3V on 3.3V boards) for HIGH, 0V (ground) for LOW.

If the pin is configured as an INPUTdigitalWrite() will enable (HIGH) or disable (LOW) the internal pullup on the input pin. It is recommended to set the pinMode() to INPUT_PULLUP to enable the internal pull-up resistor.

If you do not set the pinMode() to OUTPUT, and connect an LED to a pin, when calling digitalWrite(HIGH), the LED may appear dim. Without explicitly setting pinMode()digitalWrite() will have enabled the internal pull-up resistor, which acts like a large current-limiting resistor.

Syntax

digitalWrite(pin, value)

Parameters

pin: the Arduino pin number.
valueHIGH or LOW.

Returns

Nothing



delay()

Description

Pauses the program for the amount of time (in milliseconds) specified as parameter. (There are 1000 milliseconds in a second.)

Syntax

delay(ms)

Parameters

ms: the number of milliseconds to pause. Allowed data types: unsigned long.

Returns

Nothing



Source: https://www.arduino.cc/reference/en
